    Barite Dolomite Kaolin Small Impact Crusher For Sale

    Ask Lasest Price
    Model Number : ISP1008
    Certification : ISP1010
    Price : Negotiate
    Payment Terms : TT, L/C
    Supply Ability : 60 Set/Sets per Month
    Delivery Time : To be negotiated
    Brand Name : CN Crusher
    • Product Details
    • Company Profile

    Barite Dolomite Kaolin Small Impact Crusher For Sale

    Quick Details


    Small Impact Crusher is Mainly used for crushing hard rock, ISP Series Impact Crusher is a newly designed and developed machine with high efficiency. It is mainly used in secondary, tertiary, and fine crushing. ISp impact crusher also has certain function of shaping the products and making sand. It is widely used to process sand and aggregate in the field of construction for water and electricity, highway, city construction.


    Working Principle


    Small Impact Crusher breaks materials with impact force. When working, driven by a motor, the rotor rotates at a high speed. When materials enter the working area of hammer, they are crushed under the high-speed shock. Then broken materials are thrown onto the lining plate for another crushing. Finally, qualified materials are discharged from the opening. Adjusting the gap between the impact rack and rotor rack can change the granularity and shape of finished products.

    Parameters



    SpecificationISP1005ISP1008ISP1010
    Compression Strength(<150MPa)Medium CrushingMax. Feed Size(mm)150200200
    Discharge Size(mm)404040
    Fine CrushingMax. Feed Size(mm)80120120
    Discharge Size(mm)252525
    Compression Strength(>250MPa)Medium CrushingMax. Feed Size(mm)120150150
    Discharge Size(mm)404040
    Fine CrushingMax. Feed Size(mm)608080
    Discharge Size(mm)252525
    Capacity(t/h)~50~70~100
    Power(kw)557590
    Dimension(mm)2610×1780×21252610×1910×21252610×2275×2125

    SpecificationISP1310ISP1313ISP1513ISP1515

    Compression

    Strength

    (<150MPa)

    Medium Crushing

    Max. Feed

    Size(mm)

    300300400400

    Discharge

    Size(mm)

    40404040
    Fine Crushing

    Max. Feed

    Size(mm)

    150150200200

    Discharge

    Size(mm)

    25252525

    Compression

    Strength

    (>250MPa)

    Medium Crushing

    Max. Feed

    Size(mm)

    150150200200

    Discharge

    Size(mm)

    40404040
    Fine Crushing

    Max. Feed

    Size(mm)

    100100140140

    Discharge

    Size(mm)

    25252525
    Capacity(t/h)~150~180~200~230
    Power(kw)132160185220
    Dimension(mm)3140×2080×27153140×2330×27153235×2400×27953235×2680×2795

    Features


    1. There are two different adjustable crushing cavities of ISP impact crusher, which increases the efficiency.

    2. The anti-wear alloy hammer and impact plate increase the utilization and reduce the cost.

    3. There are special symmetric check-doors at both sides of the frame, which are convenient to change the hammer and impact plate.

    4. The discharge opening is adjustable. The final product size can be controlled. The shape of the product shows like a cube type.

    5. ISP impact crusher has smart structure ,easy to maintain, energy-saving.


    Application


    The Impact Crusher is widely used for sand and rock production in the industry of roads, railways, reservoir, electricity power, building materials, and so on.
